Physical
Bredd
130 mm
Höjd
96 mm
Djup
81 mm
Hot water meter - wM-Bus / LoRa - DN20, L130, Q3
Water meter
Hot water meter - wM-Bus / LoRa - DN20, L130, Q3
Item no:
16-30-009
Single-jet cold water meter for apartment measurement with DN20 connection and 130 mm installation length. MID-approved and equipped with built-in wireless communication via wM-Bus and LoRaWAN.
- Cold water meter with support for wM-Bus or LoRa
- MID-approved apartment meter
- Up to 13 years of battery operation
A wireless apartment meter for hot water, designed for individual water metering in multi-family buildings and properties. The meter is digital and single-jet with inductive reading, providing a modern solution for both local reading and remote meter data collection.
The meter is made of brass, has a DN20 size, PN16 pressure rating and a construction length of 130 mm. It is MID-approved and has a Q3 flow rate of 4 m³/h, and is intended for cold water up to T50. The 8-digit LCD display makes it easy to read the value directly on site.
With integrated dual-tech communication via both wM-Bus and LoRaWAN, the meter can be used in various systems for remote reading and energy/water monitoring. Its long battery life makes it well suited for long-term installations where minimal maintenance and reliable data collection are important requirements.
Technical specifications
Communication
Protocol
Wireless M-Bus, LoRaWAN
